With the high pressure or low pressure, exchange rates moderate or quick and with materials as straightforward as air and water or as unpredictable as unsafe chemicals. Therefore, all the industrial hoses applications require something somewhat extraordinary. We have the industrial hoses that can fulfill all your demands.
Examine our industrial hoses products below.
STANDARD CORRUGATED METAL HOSE (SPF TYPE)
The mechanically corrugated hose with normal corrugation can be used in extreme temperature conditions (from -270 °C to 600 °C). These hoses can prevent natural aging and are available with or without a braid. The production method ensures high leak-proof capabilities. Additionally, they are designed according to EN ISO1 0380 standards.
These standard corrugated metal hoses are ideal for chemical, petrochemical, cryogenic, nuclear, and thermal applications. Similar industries use them for fluid transfer with very high temperatures.
There are two versions:
- SPF WB – Standard corrugated metal hose without a braid
- SPFB – Standard corrugated metal hose with a braid
MAIN APPLICATIONS
- Mainly used for transporting fluids with a wide range of temperatures.
- Also suitable for static installation or for cyclic movements with weak amplitudes.
- The hose is inherently leak-proof and ideal for numerous applications in chemical, petrochemical, cryogenic, nuclear, thermal, and many other industries. Twisting should always be avoided.
| DN | DN | TYPE | Wall Thickness | Bending Radius | Bending Radius | Working Pressure at 20°C |
| [mm] | [inch] | SPF | [mm] | [one-time][mm] | [frequent][mm] | [BAR] |
| 6 | 1/4" | SPF WB | 0,18 | 15 | 60 | 18 |
| 6 | 1/4" | SPF B | 0,18 | 25 | 150 | |
| 8 | 5/18" | SPF WB | 0,18 | 16 | 124 | 13 |
| 8 | 5/18" | SPF B | 0,18 | 32 | 132 | |
| 10 | 3/8" | SPF WB | 0,18 | 18 | 130 | 9 |
| 10 | 3/8" | SPF B | 0,18 | 38 | 100 | |
| 12 | 1/2" | SPF WB | 0,15 | 20 | 140 | 7 |
| 12 | 1/2" | SPF B | 0,15 | 45 | 70 | |
| 16 | 5/8" | SPF WB | 0,18 | 28 | 160 | 5 |
| 16 | 5/8" | SPF B | 0,18 | 58 | 65 | |
| 20 | 3/4" | SPF WB | 0,18 | 32 | 170 | 3 |
| 20 | 3/4" | SPF B | 0,18 | 70 | 43 | |
| 25 | 1" | SPF WB | 0,20 | 40 | 190 | 2,5 |
| 25 | 1" | SPF B | 0,20 | 85 | 49 | |
| 32 | 1 1/4" | SPF WB | 0,20 | 50 | 260 | 2 |
| 32 | 1 1/4" | SPF B | 0,20 | 105 | 35 | |
| 40 | 1 1/2" | SPF WB | 0,25 | 60 | 300 | 2 |
| 40 | 1 1/2" | SPF B | 0,25 | 130 | 38 | |
| 50 | 2" | SPF WB | 0,25 | 70 | 320 | 1 |
| 50 | 2" | SPF B | 0,25 | 160 | 26 | |
| 65 | 2 1/2" | SPF WB | 0,30 | 115 | 460 | 1 |
| 65 | 2 1/2" | SPF B | 0,30 | 200 | 25 | |
| 80 | 3" | SPF WB | 0,40 | 130 | 660 | 1 |
| 80 | 3" | SPF B | 0,40 | 240 | 16 | |
| 100 | 4" | SPF WB | 0,40 | 160 | 750 | 1 |
| 100 | 4" | SPF B | 0,40 | 290 | 10 |
WIDE PITCH CORRUGATED METAL HOSE (WPF TYPE)
The wide passage corrugated hose with mechanical shaping is ideal for extreme conditions (from -270 °C to 600 °C). Additionally, they are resistant to aging and are available without braid. The production method ensures leak-resistant capabilities. Furthermore, the design and approval comply with EN ISO 10380 standards.They are suitable for loading and unloading tank trucks containing gas, chemicals, and other hot or cold media. It is also suitable for aggressive media.MAIN APPLICATIONS
- They can function as self-annular corrugated hoses, for example, for device pipelines or for connecting heating devices.
- Additionally, due to their wide corrugation, the food industry can use them extensively.
| DN | DN | TYPE | Surface Area | Volume | Length | Working Pressure at 20°C | Burst Pressure |
| [mm] | [inch] | WPF | [M² / M] | [IT/M] | [M] | [BAR] | [BAR] |
| 10 | 3/8" | WPF | 0.062 | 0.139 | 10-100 | 11 | 44 |
| 12 | 1/2" | WPF | 0.072 | 0.168 | 10-100 | 14 | 56 |
| 16 | 5/8" | WPF | 0.099 | 0.283 | 10-100 | 8 | 36 |
| 20 | 3/4" | WPF | 0.138 | 0.437 | 10-100 | 11 | 44 |
| 25 | 1" | WPF | 0.155 | 0.644 | 10-100 | 8 | 36 |
| 32 | 1 1/4" | WPF | 0.228 | 1.125 | 10-100 | 2 | 8 |
| 40 | 1 1/2" | WPF | 0.278 | 0.600 | 10-100 | 2 | 8 |
| 50 | 2" | WPF | 0.355 | 2.409 | 10-100 | 1.5 | 8 |
CLOSED PASS FLEXIBLE HIGH CORRUGATED METAL HOSE (CPF TYPE)
The mechanically corrugated hose with closed pitch corrugation is suitable for extreme conditions (-270 °C to 600 °C) and prevents natural aging; available with and without a single braid. Additionally, the production method ensures high tightness. These industrial hoses also comply with EN ISO 10380 standards.
They are used for the transportation of liquids and gases that require very high levels of flexibility, high or cryogenic temperatures, and longevity. Primarily utilized in the vacuum, petrochemical, nuclear technology, instrumentation, exhaust systems, and air conditioning industries, these closed pitch and highly flexible corrugated metal hoses are suitable for repetitive tasks causing a lot of vibration.
Furthermore, there are two versions.
CPF WB – Closed Pitch Corrugated Metal Hose without Braid
Additionally, CPFB – Closed Pitch Corrugated Metal Hose with Braid
MAIN APPLICATIONS
It is used to transport liquids and gases with very high demands for flexibility, reliability, and lifespan, even in challenging operating conditions (dynamic, vibrations, pressure, vacuum), e.g., in low-temperature conditions, vacuum, petrochemical, nuclear technology, instrumentation, exhaust systems, and air conditioning industry.
| DN | DN | TYPE | Bending Radius | Bending Radius | Working Pressure at 20°C |
| [mm} | [inch] | CPF | One Time | Frequent | [BAR] |
| [mm] | [mm] | ||||
| 6 | 1/4" | CPF WB | 20 | 70 | 20 |
| 6 | 1/4" | CPF B | 25 | 70 | 100 |
| 8 | 5/18" | CPF WB | 25 | 80 | 16 |
| 8 | 5/18" | CPF B | 30 | 80 | 100 |
| 10 | 3/8" | CPF WB | 30 | 90 | 10 |
| 10 | 3/8" | CPF B | 35 | 90 | 65 |
| 12 | 1/2" | CPF WB | 35 | 100 | 6 |
| 12 | 1/2" | CPF B | 40 | 100 | 50 |
| 16 | 5/8" | CPF WB | 40 | 110 | 6 |
| 16 | 5/8" | CPF B | 50 | 110 | 50 |
| 20 | 3/4" | CPF WB | 50 | 130 | 4 |
| 20 | 3/4" | CPF B | 55 | 130 | 40 |
| 25 | 1" | CPF WB | 60 | 150 | 4 |
| 25 | 1" | CPF B | 65 | 150 | 40 |
| 32 | 1 1/4" | CPF WB | 70 | 200 | 2,5 |
| 32 | 1 1/4" | CPF B | 75 | 200 | 20 |
| 40 | 1 1/2" | CPF WB | 80 | 210 | 0,5 |
| 40 | 1 1/2" | CPF B | 90 | 210 | 20 |
| 50 | 2" | CPF WB | 100 | 240 | 0,5 |
| 50 | 2" | CPF B | 110 | 240 | 20 |
STANDARD CORRUGATED FLEXIBLE METAL HOSE HEAVY VERSION (Type HSPF)
The heavy-duty version of standard corrugated flexible metal industrial hoses with standard corrugation can operate in extreme temperatures (-270°C to 600°C). They are also available with or without braiding and are resistant to aging. The production method ensures high tightness. The design and approval comply with the EN ISO1 0380 standard.
They are used for the transportation of liquid or gaseous substances that also require resistance to high pressure, such as in the chemical, petroleum, and high-pressure gas sectors, petrochemical, and other heavy industries in general.
MAIN APPLICATIONS
- For the transportation of liquid or gaseous media, which also have high requirements for pressure resistance, flexibility, and durability in hostile environments
- Also for the transfer of industrial gases in steam engines, turbines, plate presses, etc.
| DN | DN | TYPE | Wall Thickness | Bending Radius | Bending Radius | Working Pressure at 20°C |
| [mm] | [inch] | HSPF | [mm] | [one-time][mm] | [frequent][mm] | [BAR] |
| 6 | 1/4" | HSPF WB | 0,25 | 15 | 110 | 50 |
| 6 | 1/4" | HSPF B | 0,25 | 25 | 200 | |
| 8 | 5/18" | HSPF WB | 0,25 | 16 | 130 | 50 |
| 8 | 5/18" | HSPF B | 0,25 | 32 | 200 | |
| 10 | 3/8" | HSPF WB | 0,25 | 18 | 150 | 25 |
| 10 | 3/8" | HSPF B | 0,25 | 38 | 150 | |
| 12 | 1/2" | HSPF WB | 0,25 | 20 | 165 | 25 |
| 12 | 1/2" | HSPF B | 0,25 | 45 | 100 | |
| 16 | 5/8" | HSPF WB | 0,30 | 28 | 195 | 20 |
| 16 | 5/8" | HSPF B | 0,30 | 58 | 150 | |
| 20 | 3/4" | HSPF WB | 0,30 | 32 | 285 | 6 |
| 20 | 3/4" | HSPF B | 0,30 | 70 | 65 | |
| 25 | 1" | HSPF WB | 0,30 | 40 | 325 | 6 |
| 25 | 1" | HSPF B | 0,30 | 85 | 50 | |
| 32 | 1 1/4" | HSPF WB | 0,30 | 50 | 380 | 4 |
| 32 | 1 1/4" | HSPF B | 0,30 | 105 | 45 | |
| 40 | 1 1/2" | HSPF WB | 0,40 | 60 | 430 | 2,5 |
| 40 | 1 1/2" | HSPF B | 0,40 | 130 | 40 | |
| 50 | 2" | HSPF WB | 0,40 | 70 | 490 | 2,5 |
| 50 | 2" | HSPF B | 0,40 | 160 | 35 | |
| 65 | 2 1/2" | HSPF WB | 0,50 | 115 | 580 | 0,5 |
| 65 | 2 1/2" | HSPF B | 0,50 | 200 | 25 | |
| 80 | 3" | HSPF WB | 0,60 | 130 | 800 | 0,5 |
| 80 | 3" | HSPF B | 0,60 | 240 | 16 |
HEAVY VERSION WIDE PITCH CORRUGATED FLEXIBLE METAL HOSE (Type HWPF)
The wide-pitch corrugated hose with mechanical shaping is ideal for extreme conditions (from -270°C to 600°C). They are resistant to aging and are available without braiding. Additionally, the production method ensures leak-resistant capabilities. Furthermore, the design and approval comply with EN ISO 10380 standards.
These industrial hoses can operate for the transfer of liquids and gases, which also require high levels of flexibility and high temperatures. Moreover, they are used in nuclear technology, air conditioning systems, etc.
MAIN APPLICATIONS
- Used for the transportation of liquid or gaseous media, which also require high levels of pressure resistance, flexibility, and durability in extreme environmental conditions.
- For the transfer of industrial gases and in steam engines, then also in turbines and plate presses.
| DN | DN | TYPE | Wall Thickness | Surface Area | Volume | Working Pressure at 20°C |
| [mm] | [inch] | HWPF | [mm] | [M² / M] | [IT/M] | [BAR] |
| 16 | 5/8" | HWPF | 0,30 | 0,09857 | 0,2834 | 20 |
| [mm] | [inch] | HWPF | [mm] | [M² / M] | [IT/M] | [BAR] |
| 16 | 5/8" | HWPF | 0,30 | 0,09857 | 0,2834 | 20 |
| 20 | 3/4" | HWPF | 0,30 | 0,13756 | 0,4372 | 12 |
| 25 | 1" | HWPF | 0,30 | 0,15501 | 0,644 | 12 |
| 32 | 1 1/4" | HWPF | 0,30 | 0,22815 | 1,124 | 12 |
| 40 | 1 1/2" | HWPF | 0,40 | 0,27247 | 1,600 | 10 |
| 50 | 2" | HWPF | 0,40 | 0,35504 | 2,409 | 8 |
